| Expanded graphite | Flexigraf FGS1200 |
|---|---|
| Composition |
Graphite laminate reinforced with a pure alluminium alloy core
|
| Minimum density DIN 28090-2 |
1 g/cm³
|
| Maximum density DIN 28090-2 |
1.2 g/cm³
|
| Max recommended Peak Temperature |
-200 °C
|
| Max recommended Peak Temperature |
550 °C
|
| Max operating pressure |
100 bar
|
| Leakage DIN 3535-6 |
≤0.1 mg*s-1*m-1
|
| Creep relaxation DIN 3535-6 |
≤5 %
|
| Compressibility DIN 3535-6 |
30-50 %
|
| Recovery DIN 3535-6 |
3-7 %
|
| Available sheets size |
1500x1500 mm
1000x1000 mm
1500x1000 mm
|
| Available thickness |
from 0.5 to 3 mm
|
| Sheet size tolerance |
50 mm
|
| Thickness tolerance |
10 %
|
