| Mica | Mica FM High |
|---|---|
| Composition |
Expanded Mica and biosoluble fiber bonded to a SS316L tanged core
|
| Density ASTMF 1315 |
1.60-1.90 g/cm³
|
| Max recommended Peak Temperature |
950 °C
|
| Max operating pressure |
200 bar
|
| Leakage DIN 3535-6 |
<0.1* mg*s-1*m-1
|
| Creep relaxation DIN 3535-6 |
<18 %
|
| Compressibility DIN 3535-6 |
>20 %
|
| Recovery DIN 3535-6 |
>2.2 %
|
| Available sheets size |
1500x1500 mm
1000x1000 mm
|
| Available thickness |
from 1 to 3 mm
|
| Sheet size tolerance |
50 mm
|
| Thickness tolerance |
10 %
|
